Product SKUs | |
AS-2014TP-HTR | A+ Server 2014TP-HTR |
Motherboard (per Node) | |
Super H12SST-PS | |
Processor/Chipset (per Node) | |
CPU |
|
Cores | Up to 64 Cores |
Note | * Certain CPUs with high TDP may be supported only under specific conditions. Please contact Supermicro Technical Support for additional information about specialized system optimization |
System Memory (per Node) | |
Memory Capacity |
|
Memory Type | DDR4 3200 MHz Registered ECC, 288-pin gold-plated DIMMs |
Memory Sizes |
8GB, 16GB, 32GB, 64GB, 128GB, 256GB |
Memory Voltage |
1.2V |
Error Detection |
|
On-Board Devices (per Node) | |
Chipset |
System on Chip |
Storage |
SATA3 (6Gbps) via AMD EPYC |
Network Controllers |
Barebones and Complete System must have at least one SIOM installed per node |
IPMI |
|
Video |
ASPEED AST2500 BMC |
Input / Output (per Node) | |
LAN |
|
USB |
|
Video | 1 VGA port |
DOM | 1 SuperDOM (Disk on Module) port |
Others |
|
System BIOS (per Node) | |
BIOS Type | AMI 128Mb SPI Flash ROM |
Management (per Node) | |
Software |
|
Power Configurations | ACPI / APM Power Management |
Chassis | |
Form Factor | 2U Rackmount |
Model | CSE-827HQ+-R2K04BP2 |
Dimensions and Weight | |
Width | 17.25″ (438mm) |
Height | 3.47″ (88mm) |
Depth | 30.5″ (774mm) |
Package | 26.4″ (W) x 11.2″ (H) x 39.8″ (D) |
Weight |
|
Available Colors | Black |
Front Panel (per Node) | |
Buttons |
|
LEDs |
|
Expansion Slots (per Node) | |
PCI-Express |
|
M.2 |
|
Drive Bays (per Node) | |
Hot-swap |
3 Hot-swap 3.5″ SATA3 drive bays |
System Cooling | |
Fans | 4 Heavy duty 8cm PWM fans |
Power Supply (76mm Width) | |
2000W Redundant Power Supplies with PMBus | |
Total Output Power |
1000W/1800W/1980W/2000W |
Dimension (W x H x L) | 76 x 40 x 336 mm |
Input |
|
+12V |
|
+5Vsb | Max: 1A / Min: 0A |
Output Type | 27 Pairs Gold Finger Connector |
Certification |
Titanium Level
[ Test Report ] |
Operating Environment | |
RoHS | RoHS Compliant |
Environmental Spec. | Operating Temperature:
|
