Supermicro

WIO A+ Server AS-1115SV-WTNRT / 1U

Key Applications

Virtualization
Data Center Optimized
Firewall Applications
Database/Storage
Edge/Cloud Computing Services

Key Features

Single Socket AMD EPYC™ 8004 Series Processor
6 DIMM slots, DDR5-4800MHz memory, support up to 576GB
2 PCIe 5.0 x16 FHFL;

1 PCIe 5.0 x16 LP
1x dedicated IPMI LAN, 2x 10GbE BaseT LAN ports via Broadcom BCM57416 Controller
10 hot-swap 2.5″ drive bays support SATA(default)/NVMe/SAS drives or
6 SATA/NVMe Hybrid with 4 SATA drives
(Optional cables or SAS controller card for NVMe and SAS drives support)
Dual 860W Redundant Titanium Level Power Supplies

(Full redundancy based on configuration and application load)
2 On-board PCIe 3.0 x4 M.2 NVMe 80mm/110mm (Boot)

Product Specifications

Product SKUs
A+ Server AS -1115SV-WTNRT
Motherboard
Super H13SVW-NT
Processor
CPU	Single processor(s) AMD EPYC™ 8004 Series Processor
Core Count	Up to 64C/128T
Note	Supports up to 225W TDP CPUs (Air Cooled)
GPU
Max GPU Count	Up to 1 double-width or 2 single-width GPU(s)
System Memory
Memory	Slot Count: 6 DIMM slots Max Memory (1DPC): Up to 576GB 4800MT/s ECC DDR5 RDIMM
Memory Voltage	1.1 V
On-Board Devices
NVMe	NVMe (optional)
SATA	SATA (6Gbps)
Chipset	System on Chip
Network Connectivity	2x 10Gb BaseT with Broadcom BCM57416
IPMI	Support for Intelligent Platform Management Interface v.2.0 IPMI 2.0 with virtual media over LAN and KVM-over-LAN support
Input / Output
LAN	1 RJ45 Dedicated IPMI LAN port 2 RJ45 10 GbE LAN ports
USB	6 USB port(s) (2 front; 4 rear)
Video	1 VGA port(s)
Serial Port	1 COM Port(s) (1 rear)
System BIOS
BIOS Type	AMI 32MB SPI Flash EEPROM
BIOS Features	ACPI 6.4 SMBIOS 3.5 or later UEFI 2.8 Plug and Play (PnP) USB Keyboard support
Management
Software	IPMI 2.0 KVM with dedicated LAN Super Diagnostics Offline SuperDoctor® 5 Supermicro Update Manager (SUM) Supermicro Server Manager (SSM) Redfish API
Security
Hardware	Trusted Platform Module (TPM) 2.0 Silicon Root of Trust (RoT) – NIST 800-193 Compliant
Features	Cryptographically Signed Firmware Secure Boot Secure Firmware Updates Automatic Firmware Recovery Supply Chain Security: Remote Attestation Runtime BMC Protections System Lockdown
PC Health Monitoring
FAN	Fans with tachometer monitoring Pulse Width Modulated (PWM) fan connectors Status monitor for speed control
Temperature	Monitoring for CPU and chassis environment Thermal Control for fan connectors

Chassis
Form Factor	1U
Model	CSE-116BTS-R000WNP
Dimensions and Weight
Height	1.7″ (43mm)
Width	17.2″ (437mm)
Depth	23.5″ (597mm)
Package	7.75″ (H) x 23.5″ (W) x 31.5″ (D)
Weight	Net Weight: 21 lbs (9.53 kg) Gross Weight: 33.5 lbs (15.2 kg)
Available Color	Black
Expansion Slots
PCI-Express (PCIe)	2 PCIe 5.0 x16 FHFL slot(s) 1 PCIe 5.0 x16 LP slot(s)
Drive Bays / Storage
Hot-swap	10x 2.5″ hot-swap SATA/SAS/NVMe drive bays (6x 2.5″ NVMe hybrid)
M.2	PCIe 3.0 x4 M-key, 2280, 22110 View M.2 Options
System Cooling
Fans	6 Heavy duty counter-rotating 40x40x56mm Fan(s)
Power Supply
2x 860W Redundant Titanium Level power supplies
Dimension (W x H x L)	54.5 x 40.25 x 322 mm
AC Input	800W: 100-127Vac / 50-60Hz 860W: 200-240Vac / 50-60Hz 860W: 240Vdc / 50-60Hz
+12V	Max: 66.67A / Min: 0A (100Vac-127Vac) Max: 71.67A / Min: 0A (200Vac-240Vac) Max: 71.67A / Min: 0A (Vdc-240Vdc)
5V SB	Max: 4A / Min: 0A
Output Type	Backplanes (gold finger)
Operating Environment
Environmental Spec.	Operating Temperature: 10°C ~ 35°C (50°F ~ 95°F) Non-operating Temperature: -30°C to 60°C (-22°F to 140°F) Operating Relative Humidity: 8% to 80% (non-condensing) Non-operating Relative Humidity: 8% to 90% (non-condensing)

Speak with an expert to learn more.
