Supermicro

UP SuperServer SYS-510P-M / 1U

Key Applications

Small Business
Web/Hosting Application
Email/Firewall/Print Server

Key Features

Single Socket P+ (LGA-4189) 3rd Gen Intel® Xeon® Scalable processors. Up to 220W TDP.
8 DIMMs; Supports 3DS DDR4-3200: RDIMM/LRDIMM/Intel® DCPMM
1 PCIe 4.0 x16 (FHHL) slot
Intel® Ethernet Controller i350 2x 1GbE RJ45
4x hot-swap 3.5” Hybrid SATA3/NVMe drive bays, SAS3 with additional SAS controller card; Onboard 2x NVMe/SATA M.2
Single Platinum 500W Power Supply

Product Specifications

Product SKUs
SuperServer SYS-510P-M
Motherboard
Super X12SPO-F
Processor
CPU	Single Socket P+ (LGA-4189) 3rd Gen Intel® Xeon® Scalable processors
Core Count	Up to 36C/72T; Up to 54MB Cache
Note	Supports up to 220W TDP CPUs (Air Cooled)
System Memory
Memory	Slot Count: 8 DIMM slots Max Memory (2DPC): Up to 2TB 3200MT/s ECC DDR4 RDIMM/LRDIMM Supports Intel® Optane™ persistent memory 200 series
Memory Voltage	1.2 V
On-Board Devices
SATA	SATA3 (6Gbps); RAID 0/1/5/10 support
NVMe	NVMe; RAID 0/1/5/10 support (*VROC HW key is required)
Chipset	Intel® C621A
Network Connectivity	2x 1GbE BaseT with Intel® i350
IPMI	Support for Intelligent Platform Management Interface v.2.0 IPMI 2.0 with virtual media over LAN and KVM-over-LAN support
Input / Output
SATA	10 SATA (6Gbps) port(s)
LAN	1 RJ45 Dedicated IPMI LAN port 2 RJ45 1GbE LAN ports
USB	5 USB 3.2 Gen 1 port(s) (2 headers; 2 rear; 1 Type A) 6 USB 2.0 port(s) (4 headers; 2 rear)
Video	1 VGA port(s)
Serial Port	2 COM Port(s) (1 header; 1 rear)
DOM	2 SuperDOM (Disk on Module) port with built-in power
System BIOS
BIOS Type	AMI 32MB SPI Flash EEPROM
Management
Software	IPMI 2.0 KVM with dedicated LAN Super Diagnostics Offline SuperDoctor® 5 Supermicro Update Manager (SUM) Supermicro Power Manager (SPM) Supermicro Server Manager (SSM) Redfish API
Power Configurations	ACPI/APM Power Management
Security
Hardware	Trusted Platform Module (TPM) 2.0 Silicon Root of Trust (RoT) – NIST 800-193 Compliant
Features	Cryptographically Signed Firmware Secure Boot Secure Firmware Updates Automatic Firmware Recovery System Lockdown
PC Health Monitoring
CPU	7+1 Phase-switching voltage regulator Monitors for CPU Cores, Chipset Voltages, Memory
FAN	Fans with tachometer monitoring Pulse Width Modulated (PWM) fan connectors Status monitor for speed control
Temperature	Monitoring for CPU and chassis environment Thermal Control for fan connectors

Chassis
Form Factor	1U Rackmount
Model	CSE-813MF2TS-505CBP
Dimensions and Weight
Height	1.7″ (43mm)
Width	17.2″ (437mm)
Depth	19.98″ (507mm)
Package	8.5″ (H) x 24″ (W) x 29.5″ (D)
Weight	Net Weight: 17.6 lbs (8 kg) Gross Weight: 30.4 lbs (13.8 kg)
Available Color	Black
Front Panel
Buttons	Power On/Off System Reset
LEDs	Device Activity LAN 1 Activity LAN 2 Activity Power status System information
Expansion Slots
PCI-Express (PCIe)	1 PCIe 4.0 x16 FHHL slot(s)
Drive Bays / Storage
Drive Bays	4x 3.5″ NVMe/SATA drive bays (4x 3.5″ NVMe hybrid)
M.2	2x PCIe 3.0 x 4 and SATA M-key, 2280, 22110 View M.2 Options
Peripheral Bays	2x 2.5″ drive bays
System Cooling
Fans	2 AOC cooling Fan(s) (optional) 4 middle cooling PWM 40x40x28mm Fan(s)
Power Supply
500W Platinum Level power supply
Dimension (W x H x L)	100 x 40 x 180 mm
AC Input	500W: 100-240Vac / 50-60Hz
+12V	Max: 41A / Min: 0.5A (100Vac-240Vac)
5V SB	Max: 3A / Min: 0A
Output Type	24pin ATX
Certification	Platinum Level [ Test Report ]
Operating Environment
Environmental Spec.	Operating Temperature: 10°C ~ 35°C (50°F ~ 95°F) Non-operating Temperature: -40°C to 70°C (-40°F to 158°F) Operating Relative Humidity: 8% to 90% (non-condensing) Non-operating Relative Humidity: 5% to 95% (non-condensing)
