Storage SuperServer SSG-610P-ACR12N4H / 1U

Key Applications

  • Database Applications
  • Hyperscale Data Center
  • Object Storage
  • Big Data Analytics
  • Scale-Out Density
  • Hadoop & Ceph storage solutions
  • Scale-out NAS

Key Features

  1. Up to 4TB ECC DDR4-3200: LRDIMM/RDIMM
  2. 2x 25G SFP+ Ports Onboard
  3. 12x 3.5″ hot-swap SAS/SATA, 4x hot-swap EDSFF Short Bays, 2x 2.5″ 7mm NVMe/Hot-Swap SATA drive bays
    4x E1.S (EDSFF Short) NVMe drives
  4. RAID support via Broadcom® 3916
  5. 2x 25Gb SFP28 onboard
    Front LED Indicator for each drive
    PCIe 4.0 x16 AIOM Support + 3 PCIe 4.0 LP Slots

Categories

Download datasheet

Product Specifications

Product SKUs
SuperServer SSG-610P-ACR12N4H Standard version with PWS-804P-1R (Platinum Level)
SuperServer SSG-610P-ACR12N4H-EU European version with PWS-862A-1R (Titanium Level)
Motherboard
Super X12DPD-A6M25
Processor
CPU
  • Dual Socket P+ (LGA-4189)
  • 3rd Gen Intel® Xeon® Scalable processors
Core Count Up to 38C/76T; Up to 57MB Cache per CPU
Note Supports 120W – 205W TDP CPUs (Air Cooled)
System Memory
Memory
  • Slot Count: 16 DIMM slots
  • Max Memory (2DPC): Up to 4TB 3200MT/s ECC DDR4 RDIMM/LRDIMM
Memory Voltage 1.2 V
On-Board Devices
Chipset Intel® C621A
Network Connectivity 2x 25GbE SFP28 with Mellanox®
IPMI
  • Support for Intelligent Platform Management Interface v.2.0
  • IPMI 2.0 with virtual media over LAN and KVM-over-LAN support
Input / Output
LAN
  • 1 RJ45 Dedicated IPMI LAN port
  • 1x 25G SFP+ LAN ports
USB
  • 2 USB 2.0 port(s) (2 Front_USB)
  • 2 USB 3.0 port(s) (2 Rear_USB)
Video 1 VGA port(s)
Serial Port 1 Serial
System BIOS
BIOS Type AMI 128MB SPI Flash EEPROM
Management
Software
Power Configurations
  • ACPI Power Management
  • Power-on mode for AC power recovery
Security
Hardware
  • Trusted Platform Module (TPM) 2.0
  • Silicon Root of Trust (RoT) – NIST 800-193 Compliant
Features
  • Cryptographically Signed Firmware
  • Secure Boot
  • Secure Firmware Updates
  • Automatic Firmware Recovery
  • System Lockdown
PC Health Monitoring
CPU
  • 4+1 Phase-switching voltage regulator
  • Monitors for CPU Cores, Chipset Voltages, Memory
FAN
  • Fans with tachometer monitoring
  • Pulse Width Modulated (PWM) fan connectors
  • Status monitor for speed control
Temperature
  • Monitoring for CPU and chassis environment
  • Thermal Control for fan connectors
Chassis
Form Factor 1U Rackmount
Model CSV-802ETS-R804AMP
Dimensions and Weight
Height 1.7″
Width 17.6″
Depth 37″
Package 12″ (H) x 27″ (W) x 53.15″ (D)
Weight
  • Net Weight: 34 lbs (15.4 kg)
  • Gross Weight: 61 lbs (27.7 kg)
Available Color Silver
Front Panel
Buttons Power On/Off
LEDs
  • HDD activity
  • Network activity
  • Power status
  • System information (overheat/UID)
Expansion Slots
PCI-Express (PCIe)
  • 2 PCIe 4.0 x16 LP slot(s)
  • 1 PCIe 4.0 x8 LP slot(s)
  • 1 PCIe 4.0 x16 AIOM slot(s)
Note PCIe slot 2 is occupied by the Storage Controller
Drive Bays / Storage
Hot-swap
  • 12x 3.5″ hot-swap SATA3/SAS3 drive bays
  • 4x E1.S and 2x 2.5″ 7mm
M.2
System Cooling
Fans 6 Heavy Duty 4cm Fan(s)
Power Supply
800W Redundant Platinum Level power supplies
Note: SSG-610P-ACR12N4H-EU (European) SKU uses PWS-862A-1R (Titanium Level)
Dimension (W x H x L) 54.5 x 40.25 x 220 mm
AC Input
  • 750W: 100-127Vac / 50-60Hz
  • 800W: 200-240Vac / 50-60Hz
  • 800W: 230-240Vdc / 50-60Hz
+12V
  • Max: 62.5A / Min: 0.5A (100Vac-127Vac)
  • Max: 66.6A / Min: 0.5A (200Vac-240Vac)
  • Max: 66.6A / Min: 0.5A (230Vdc-240Vdc)
5V SB Max: 4A / Min: 0A
Output Type Backplanes (gold finger)
Operating Environment
RoHS RoHS Compliant
Environmental Spec. Operating Temperature:
  • 10°C ~ 35°C (50°F ~ 95°F)
Non-operating Temperature:
  • -40°C to 60°C (-40°F to 140°F)
Operating Relative Humidity:
  • 8% to 90% (Non-Condensing)
Non-operating Relative Humidity:
  • 5% to 95% (Non-Condensing)
