Storage SuperServer SSG-222B-NE3X24R / 2U

Key Applications

  • Software-defined Storage
  • In-Memory Computing
  • Scale Out All-Flash NVMe Storage
  • Data Intensive HPC
  • Private & Hybrid Cloud
  • NVMe Over Fabrics Solution
  • AI/Deep Learning Training and Inference

Key Features

    • Dual Socket E2 (LGA-4710) Intel® Xeon® 6 6700 series processors
    • Support CPU TDP up to 350W with air cooling
  2. Up to 32 DIMMs supporting up to 8TB DDR5-6400 in 2DPC
  3. Flexible networking with up to 2 OCP 3.0 compatible AIOM slots
  4. Up to 2 PCIe 5.0 x16 FHHL + 1 PCIe 5.0 x8 FHHL + 2 PCIe 5.0 x16 AIOM slots
    • Up to 32 front hot-swap E3.S 1T NVMe drive bays
    • Up to 8 CXL 2.0 x8 Type 3 devices
  6. Up to 2 double-width GPUs (Max TDP 300W)

Categories

Download datasheet

Product Specifications

Product SKUs SuperServer SSG-222B-NE3X24R
Motherboard Super X14DBHM
Processor
CPU Dual Socket E2 (LGA-4710), Intel® Xeon® 6700 series processors with E-cores
Core Count Up to 144C/144T; Up to 108MB Cache per CPU
Note Supports up to 350W TDP CPUs (Air Cooled)
GPU
Max GPU Count Up to 2 double-width GPUs
CPU-GPU Interconnect PCIe 5.0 x16 CPU-to-GPU Interconnect
GPU-GPU Interconnect PCIe
System Memory
Memory
  • Slot Count: 32 DIMM slots/2 Channels
  • Max Memory (1DPC): Up to 4TB 6400MT/s ECC DDR5 RDIMM/LRDIMM
  • Max Memory (2DPC): Up to 8TB 5200MT/s ECC DDR5 RDIMM/LRDIMM
  • View Memory Options
On-Board Devices
NVMe NVMe; RAID 0/1/5/10 support (VROC HW key required)
Chipset System on Chip
Network Connectivity
Input / Output
LAN 1 RJ45 1 GbE Dedicated BMC LAN port
USB 2 USB 3.0 ports (rear)
Video 1 VGA port
System BIOS AMI 64MB SPI Flash
Management
Software
  • SuperCloud Composer
  • Supermicro Server Manager (SSM)
  • Super Diagnostics Offline (SDO)
  • Supermicro Thin-Agent Service (TAS)
  • SuperServer Automation Assistant (SAA) New!
Power configurations Power-on mode for AC power recovery, ACPI Power Management
Security
Hardware Trusted Platform Module (TPM) 2.0, Silicon Root of Trust (RoT) – NIST 800-193 Compliant
Features
  • Cryptographically Signed Firmware
  • Secure Boot
  • Secure Firmware Updates
  • Automatic Firmware Recovery
  • Supply Chain Security: Remote Attestation
  • Runtime BMC Protections
  • System Lockdown
PC Health Monitoring
CPU Monitors for CPU Cores, Chipset Voltages, Memory
7 Phase-switching voltage regulator
FAN Fans with tachometer monitoring, Status monitor for speed control, Pulse Width Modulated (PWM) fan connectors
Temperature Monitoring for CPU and chassis environment, Thermal Control for fan connectors
Chassis 2U Rackmount
Model CSE-246E3-R2K09P
Dimensions and Weight
Height 3.47″ (88 mm)
Width 17.25″ (438 mm)
Depth 30.7″ (780 mm)
Package 9.4″ (H) x 23.5″ (W) x 43.2″ (D)
Weight
  • Gross Weight: 83.78 lbs (38 kg)
  • Net Weight: 61.73 lbs (28 kg)
Available Color Silver
Front Panel
LED
  • HDD activity
  • LAN1 activity
  • LAN2 activity
  • Power Fail
  • Power status
  • System information (overheat/UID)
Buttons UID button
Expansion Slots
PCI-Express (PCIe) Configuration
  • Default: 2 PCIe 5.0 x16 FHFL double-width slots, 2 PCIe 5.0 x16 AIOM slots (OCP 3.0 compatible), 1 PCIe 5.0 x8 FHFL double-width slot
  • Option A: 1 PCIe 5.0 x8 FHFL double-width slot, 2 PCIe 5.0 x16 AIOM slots (OCP 3.0 compatible)
  • Option B: 1 PCIe 5.0 x8 FHFL double-width slot, 2 PCIe 5.0 x16 AIOM slots (OCP 3.0 compatible)
  • Option C: 2 PCIe 5.0 x16 FHFL double-width slots, 2 PCIe 5.0 x16 AIOM slots (OCP 3.0 compatible), 1 PCIe 5.0 x8 FHFL double-width slot
  • View AOC Options
CXL Support Up to 8 CXL 2.0 x8 Type 3 devices
Drive Bays / Storage
Drive Bays Configuration
  • Default: Total 24 bays, 24 front hot-swap E3.S 1T PCIe 5.0 x4 NVMe drive bays
  • Option A: Total 32 bays, 32 front hot-swap E3.S 1T PCIe 5.0 x4 NVMe drive bays
  • Option B: Total 24 bays, 16 front hot-swap E3.S 1T PCIe 5.0 x4 NVMe drive bays, 8 front fixed E3.S 2T PCIe 5.0 x8 CXL Type 3 drive bays
  • Option C: Total 16 bays, 8 front hot-swap E3.S 1T PCIe 5.0 x4 NVMe drive bays, 8 front fixed E3.S 2T PCIe 5.0 x8 CXL Type 3 drive bays
  • View NVMe Options
M.2
System Cooling
Fans 4x 8cm heavy duty fans with optimal fan speed control
Air Shroud 1 Air Shroud
Power Supply
2x 2000W Redundant (1 + 1) Titanium Level (96%) power supplies
Dimension (WxHxL) 73.5 x 40 x 185 mm
Input
  • 1000W: 100-127Vac / 50-60Hz
  • 1800W: 200-220Vac / 50-60Hz
  • 1980W: 220-230Vac / 50-60Hz
  • 2000W: 220-240Vac / 50-60Hz (for UL only)
  • 2000W: 230-240Vac / 50-60Hz
  • 2000W: 230-240Vdc / 50-60Hz (for CQC only)
+12V
  • Max: 83A / Min: 0A (100Vac-127Vac)
  • Max: 150A / Min: 0A (200Vac-220Vac)
  • Max: 165A / Min: 0A (220Vac-230Vac)
  • Max: 166A / Min: 0A (230Vac-240Vac)
12V SB Max: 3.5A / Min: 0A
Output Type Backplanes (gold finger)
Operating Environment
ROHS RoHS Compliant
Environmental Spec.
  • Operating Temperature: 10°C ~ 35°C (50°F ~ 95°F)
  • Non-operating Temperature: -40°C to 60°C (-40°F to 140°F)
  • Operating Relative Humidity: 8% to 90% (Non-Condensing)
  • Non-operating Relative Humidity: 5% to 95% (Non-Condensing)
Environmental / Recycling Return Server-End of Life Product
