Storage SuperServer SSG-221E-DN2R24R / 2U | Taknet
  • Supermicro

Storage SuperServer SSG-221E-DN2R24R / 2U

Key Applications

  • Artificial Intelligence (AI)
  • High Availability Storage
  • NVMe Over Fabrics Solution

Key Features

Two hot-pluggable systems (nodes) in a 2U form factor. Each node supports the following:
  1. Single Socket E (LGA-4677) 5th/4th Generation Intel® Xeon® Scalable processor. Up to 350W TDP.
    • 2 PCIe 5.0 x16 HHHL slots
    • 2 PCIe 5.0 x8 HHHL slots
  3. Supports 8 DIMMs per node with 1DPC, up to 2TB memory capacity with 8 DIMMs of 256GB 3DS RDIMM DDR5-5600 ECC memory per node.
  4. Dedicated 1GbE Private Ethernet connection for node-to-node communication (Heartbeat)
  5. 24 Hot-swap Dual Port Gen 5 U.2 NVMe SSD bays
  6. Redundant Titanium 2000W Power Supplies

Categories

Download datasheet

Product Specifications

Product SKUs SuperServer SSG-221E-DN2R24R
Motherboard Super X13SEB-TF
Processor (per Node)
CPU Single Socket E (LGA-4677), 5th Gen Intel® Xeon® / 4th Gen Intel® Xeon® Scalable processors
Note Supports 150W – 350W TDP CPUs (Air Cooled)
System Memory (per Node)
Memory
  • Slot Count: 8 DIMM slots/8 Channels
  • Max Memory (1DPC): Up to 2TB 5600MT/s ECC DDR5 RDIMM/LRDIMM
  • View Memory Options
On-Board Devices (per Node)
Chipset System on Chip
Network Connectivity
Input / Output (per Node)
LAN 1 RJ45 1 GbE Dedicated BMC LAN port, 2 RJ45 10 GbE LAN ports
USB 2 USB 3.0 ports (rear)
Video 1 VGA port
Serial 1 COM port (Rear)
System BIOS AMI 32MB SPI Flash EEPROM
Management
Software
  • SuperCloud Composer
  • Supermicro Server Manager (SSM)
  • Supermicro Update Manager (SUM)
  • Supermicro SuperDoctor® 5 (SD5)
  • Super Diagnostics Offline (SDO)
  • Supermicro Thin-Agent Service (TAS)
  • SuperServer Automation Assistant (SAA) New!
Power configurations Power-on mode for AC power recovery, ACPI Power Management
Security
Hardware Trusted Platform Module (TPM) 2.0, Silicon Root of Trust (RoT) – NIST 800-193 Compliant
Features
  • Cryptographically Signed Firmware
  • Secure Boot
  • Secure Firmware Updates
  • Automatic Firmware Recovery
  • Supply Chain Security: Remote Attestation
  • Runtime BMC Protections
  • System Lockdown
PC Health Monitoring
CPU Monitors for CPU Cores, Chipset Voltages, Memory, 7 Phase-switching voltage regulator
FAN Fans with tachometer monitoring, Status monitor for speed control, Pulse Width Modulated (PWM) fan connectors
Temperature Monitoring for CPU and chassis environment, Thermal Control for fan connectors
Chassis 2U Rackmount
Model CSE-229TS-R000NP
Dimensions and Weight
Height 3.47″ (88 mm)
Width 17.7″ (449.4 mm)
Depth 30″ (762 mm)
Package 9.64″ (H) x 26.37″ (W) x 43.3″ (D)
Weight
  • Gross Weight: 89.63 lbs (40.66 kg)
  • Net Weight: 66.82 lbs (30.31 kg)
Available Color Silver
Front Panel
LED HDD activity, LAN1 activity, LAN2 activity, Power Fail, Power status, System information (overheat/UID)
Buttons Power On/Off button, UID button
Expansion Slots (per Node)
PCI-Express (PCIe) Configuration
M.2 2 M.2 PCIe 3.0 x4 NVMe slots (M-key)
Drive Bays / Storage (per Node)
Drive Bays Configuration
  • Default: Total 24 bays, 24 front hot-swap 2.5″ PCIe 5.0 NVMe drive bays
  • View NVMe Options
M.2 2 M.2 NVMe slots (M-key 2280/22110)
System Cooling
Fans 6 Heavy Duty 6cm Fan(s)
Power Supply
2x 2000W Redundant Titanium Level (96%) power supplies
Dimension (WxHxL) 73.5 x 40 x 203 mm
Input
  • 1000W: 100-127Vac / 50-60Hz
  • 1800W: 200-220Vac / 50-60Hz
  • 1980W: 220-230Vac / 50-60Hz
  • 2000W: 220-240Vac / 50-60Hz (for UL only)
  • 2000W: 230-240Vdc / 50-60Hz (for China only)
+12V
  • Max: 83A / Min: 0A (100Vac-127Vac)
  • Max: 150A / Min: 0A (200Vac-220Vac)
  • Max: 165A / Min: 0A (220Vac-230Vac)
  • Max: 166A / Min: 0A (230Vac-240Vac)
12V SB Max: 3.5A / Min: 0A
Output Type Backplanes (gold finger)
Operating Environment
ROHS RoHS Compliant
Environmental Spec.
  • Operating Temperature: 10°C ~ 35°C (50°F ~ 95°F)
  • Non-operating Temperature: -40°C to 60°C (-40°F ~ 140°F)
  • Operating Relative Humidity: 8% to 90% (Non-Condensing)
  • Non-operating Relative Humidity: 5% to 95% (Non-Condensing)
