GPU SuperServer SYS-A22GA-NBRT / 10U

Key Applications

  • AI / Deep Learning
  • Scientific Research
  • Conversational AI
  • Drug Discovery
  • High Performance Computing (HPC)

Key Features

  1. Dual Intel® Xeon® 6900 series processors with P-cores, up to 500W TDP, 6UPI
  2. Supports 8 onboard SXM B200 GPU accelerators
  3. 24 DIMM slots, ECC RDIMM / MRDIMM DDR5, up to 6400MT/s (1DPC only)
  4. 2 10G NIC (X710), 1 VGA, 2 USB 3.0, and 1 Dedicated IPMI
  5. 10 PCIe 5.0 x16 LP and 2 PCIe 5.0 x16 FHHL
  6. 10 PCIe 5.0 NVMe U.2 and 2 NVMe M.2

Categories

Download datasheet

Product Specifications

Product SKUs
SuperServer SYS-A22GA-NBRT
Motherboard
Super X14DBG-DAP
Processor
CPU
Core Count Up to 128C/256T; Up to 504MB Cache per CPU
Note Supports up to 500W TDP CPUs (Air Cooled)
GPU
Max GPU Count 8 onboard GPUs
Supported GPU NVIDIA SXM: HGX B200 8-GPU (180GB) View GPU Options
CPU-GPU Interconnect PCIe 5.0 x16 CPU-to-GPU Interconnect
GPU-GPU Interconnect NVIDIA® NVLink® with NVSwitch™
System Memory
Memory
  • Slot Count: 24 DIMM slots
  • Max Memory (1DPC): Up to 6TB 6400MT/s ECC DDR5 RDIMM
  • Max Memory (1DPC): Up to 6TB 8800MT/s ECC DDR5 MRDIMM
Memory Voltage 1.1V
On-Board Devices
Chipset System on Chip
Network Connectivity
  • 2 RJ45 10GbE with Intel® X710
Input / Output
LAN 1 RJ45 1 GbE Dedicated BMC LAN port
USB 2 USB 3.0 ports (rear)
Video 1 VGA port
TPM 1 TPM header
System BIOS
BIOS Type AMI 64MB SPI Flash
Management
Software
  • SuperCloud Composer
  • Supermicro Server Manager (SSM)
  • Super Diagnostics Offline (SDO)
  • Supermicro Thin-Agent Service (TAS)
  • SuperServer Automation Assistant (SAA) New!
Power Configurations
  • Power-on mode for AC power recovery
  • ACPI Power Management
Security
Hardware
  • Trusted Platform Module (TPM) 2.0
  • Silicon Root of Trust (RoT) – NIST 800-193 Compliant
Features
  • Cryptographically Signed Firmware
  • Secure Boot
  • Secure Firmware Updates
  • Automatic Firmware Recovery
  • Supply Chain Security: Remote Attestation
  • Runtime BMC Protections
  • System Lockdown
PC Health Monitoring
CPU
  • Monitors for CPU Cores, Chipset Voltages, Memory
FAN
  • Fans with tachometer monitoring
  • Status monitor for speed control
  • Pulse Width Modulated (PWM) fan connectors
Temperature
  • Monitoring for CPU and chassis environment
  • Thermal Control for fan connectors
Chassis
Form Factor 10U Rackmount
Model CSE-GP1001TS-R000NPF
Dimensions and Weight
Height 17.2″ (438.8 mm)
Width 17.6″ (449 mm)
Depth 33.2″ (843.28 mm)
Package 25.2″ (H) x 49.4″ (W) x 27.3″ (D)
Weight
  • Gross Weight: 183 lbs (83.1 kg)
  • Net Weight: 122.7 lbs (55.64 kg)
Available Color Silver
Front Panel
LED
  • HDD activity
  • Network activity LEDs
  • System information (overheat/UID)
  • UID
Buttons
  • Power On/Off
  • UID/ Reset button
Expansion Slots
PCI-Express (PCIe) Configuration
  • Default
  • 8 PCIe 5.0 x16 LP slots
  • 2 PCIe 5.0 x16 FHHL slots
  • Option A: 2 PCIe 5.0 x16 LP slots
Drive Bays / Storage
Drive Bays Configuration
  • Default: Total 10 bays
  • 10 front hot-swap 2.5″ PCIe 5.0 x4 NVMe drive bays
M.2 2 M.2 PCIe 4.0 x4 NVMe slots (M-key 2280/22110/25110)
System Cooling
Fans 19 counter-rotating 80x80x38mm Fan(s)
Air Shroud 1 Air Shroud
Power Supply
6x 5250W Redundant (3 + 3) power supplies
Dimension (W x H x L) 106.5 x 82.1 x 245.3 mm
Input 5250W: 200-240Vac / 50-60Hz
+12V Max: 125A / Min: 0A (200Vac-240Vac)
12V SB Max: 4A / Min: 0A
Output Type Backplanes (gold finger)
Certification [ Test Report ]
Operating Environment
Environmental Spec. Operating Temperature:
  • 10°C ~ 35°C (50°F ~ 95°F)
Non-operating Temperature:
  • -40°C to 70°C (-40°F to 158°F)
Operating Relative Humidity:
  • 8% to 90% (non-condensing)
Non-operating Relative Humidity:
  • 5% to 95% (non-condensing)
