GPU SuperServer SYS-422GA-NBRT-LCC / 4U

Key Applications

  • High Performance Computing
  • AI/Deep Learning Training
  • Industrial Automation, Retail
  • Healthcare
  • Conversational AI
  • Business Intelligence & Analytics
  • Drug Discovery
  • Climate and Weather Modeling
  • Finance & Economics

Key Features

  1. Dual Intel® Xeon® 6900 series processors with P-cores, up to 500W TDP, 6UPI
  2. Support for up to 8 onboard SXM GPU accelerator cards
  3. 24 DIMM slots, ECC DDR5 designed for up to 6400MT/s (1DPC only)
  4. 2 10G NIC (X710), 1 VGA, 2 USB 3.0, and 1 Dedicated IPMI
  5. 8 PCIe 5.0 x16 LP and 2 PCIe 5.0 x16 FHHL
  6. Up to 8 front hot-swap 2.5″ NVMe drive bays and 2 NVMe M.2

Categories

Download datasheet

Product Specifications

Product SKUs
SuperServer SYS-422GA-NBRT-LCC
Motherboard
Super X14DBG-DAP
Processor
CPU
  • Dual Socket BR (LGA-7529)
  • Intel® Xeon® 6900 series processors with P-cores
Core Count Up to 128C/256T; Up to 504MB Cache per CPU
Note Supports up to 500W TDP CPUs (Liquid Cooled)
GPU
Max GPU Count Up to 8 onboard GPUs
Supported GPU
CPU-GPU Interconnect PCIe 5.0 x16 CPU-to-GPU Interconnect
GPU-GPU Interconnect NVIDIA® NVLink® with NVSwitch™
System Memory
Memory
  • Slot Count: 24 DIMM slots
  • Max Memory (1DPC): Up to 6TB 6400MT/s ECC DDR5 RDIMM
  • Max Memory (1DPC): Up to 6TB 8800MT/s ECC DDR5 MRDIMM
  • View Memory Options
On-Board Devices
Chipset System on Chip
Network Connectivity
Input / Output
Video 1 VGA port
System BIOS
BIOS Type AMI 32MB SPI Flash EEPROM
Management
Software
  • SuperCloud Composer
  • Supermicro Server Manager (SSM)
  • Super Diagnostics Offline (SDO)
  • Supermicro Thin-Agent Service (TAS)
  • SuperServer Automation Assistant (SAA) New!
Power Configurations
  • Power-on mode for AC power recovery
  • ACPI Power Management
Security
Hardware
  • Trusted Platform Module (TPM) 2.0
  • Silicon Root of Trust (RoT) – NIST 800-193 Compliant
Features
  • Cryptographically Signed Firmware
  • Secure Boot
  • Secure Firmware Updates
  • Automatic Firmware Recovery
  • Supply Chain Security: Remote Attestation
  • Runtime BMC Protections
  • System Lockdown
PC Health Monitoring
CPU
  • Monitors for CPU Cores, Chipset Voltages, Memory
  • 8+4 Phase-switching voltage regulator
FAN
  • Fans with tachometer monitoring
  • Status monitor for speed control
  • Pulse Width Modulated (PWM) fan connectors
Temperature
  • Monitoring for CPU and chassis environment
  • Thermal Control for fan connectors
Chassis
Form Factor 4U Rackmount
Model CSE-GP403TS-R000NP
Dimensions and Weight
Height 13.8″ (174 mm)
Width 17.7″ (449 mm)
Depth 34.62″ (879.4 mm)
Package 13″ (H) x 48″ (W) x 26.4″ (D)
Weight N/A
Available Color Silver
Front Panel
LED
  • HDD activity
  • System information (overheat/UID)
  • UID
Buttons
  • Power On/Off
  • UID/ Reset button
Expansion Slots
PCI-Express (PCIe) Configuration
  • Default: 8 PCIe 5.0 x16 LP slots, 2 PCIe 5.0 x16 FHHL slots
  • Option A: 8 PCIe 4.0 x16 LP slots, 4 PCIe 5.0 x16 FHHL slots
  • View AOC Options
Drive Bays / Storage
Drive Bays Configuration
M.2
  • 2 M.2 NVMe slots (M-key)
System Cooling
Fans 4 Fan 8cm Fan(s)
Liquid Cooling Direct to Chip (D2C) Cold Plate (optional)
Power Supply
4x 6600W Redundant (2 + 2) Titanium Level (96%) power supplies
Dimension (W x H x L) 106.5 x 82.1 x 245.3 mm
Input
  • 5900W: 200-207.9Vac / 50-60Hz
  • 6000W: 208-219.9Vac / 50-60Hz
  • 6300W: 220-229.9Vac / 50-60Hz
  • 6500W: 230-238.9Vac / 50-60Hz
  • 6600W: 239-240Vac / 50-60Hz
+12V
  • Max: 130A / Min: 0A (200Vac-207.9Vac)
  • Max: 130A / Min: 0A (208Vac-219.9Vac)
  • Max: 130A / Min: 0A (220Vac-229.9Vac)
  • Max: 130A / Min: 0A (230Vac-238.9Vac)
  • Max: 130A / Min: 0A (239Vac-240Vac)
12V SB Max: 4A / Min: 0A
Output Type Backplanes (gold finger)
Certification 80 Plus Titanium Level
Operating Environment
Environmental Spec. Operating Temperature:
  • 10°C ~ 35°C (50°F ~ 95°F)
Non-operating Temperature:
  • -40°C to 60°C (-40°F to 140°F)
Operating Relative Humidity:
  • 8% to 90% (non-condensing)
Non-operating Relative Humidity:
  • 5% to 95% (non-condensing)
