GPU ARS-221GL-NHIR / 2U | Taknet
  • Supermicro

GPU ARS-221GL-NHIR / 2U

Key Applications

  • High Performance Computing
  • AI/Deep Learning Training and Inference
  • Large Language Model (LLM) and Generative AI

Key Features

  1. High density 2U 1-node GPU system with two Integrated NVIDIA H100 GPUs and two 72-core Arm Neoverse V2 CPUs NVIDIA® NVLink® high speed interconnect between both GH200 Super Chips
  2. NVIDIA Grace™ Hopper Superchip (Grace CPU and H100 GPU)
  3. NVLink® Chip-2-Chip (C2C) high-bandwidth, low-latency interconnect between CPU and GPU at 900GB/s
  4. Up to 1248GB of coherent memory (system as a whole), including 960GB LPDDR5X and 288GB of HBM3e for LLM applications
  5. 4x PCIe 5.0 X16 supporting one NVIDIA Bluefield 3 and two connectX-7 cards
  6. 6 Heavy Duty Fans with Optional Speed Control

Categories

Download datasheet

Product Specifications

Product SKUs
SuperServer ARS-221GL-NHIR
Motherboard
Super G2DMH-GI
Processor
CPU NVIDIA 72-core NVIDIA Grace CPU on GH200 Grace Hopper™ Superchip
Note Supports up to 300W TDP CPUs (Air Cooled)
GPU Max GPU Count: 2 onboard GPUs
Supported GPU
  • NVIDIA: H100 Tensor Core GPU on GH200 Grace Hopper™ Superchip (Air-cooled)
  • View GPU Options
CPU-GPU Interconnect NVLink®-C2C
GPU-GPU Interconnect NVIDIA® NVLink®
System Memory
Memory
  • Slot Count: Onboard Memory
  • Max Memory: Up to 960GB ECC LPDDR5X
  • Additional GPU Memory: Up to 288GB ECC HBM3e
On-Board Devices
Chipset System on Chip
Network Connectivity View AOC Options
Input / Output
LAN 1 RJ45 1 GbE Dedicated BMC LAN port
USB 1 port(Rear)
Video 1 mini-DP port
System BIOS
BIOS Type AMI 64MB UEFI
Management
Power Configurations
  • Power-on mode for AC power recovery
  • ACPI Power Management
PC Health Monitoring
CPU Monitors for CPU Cores, Chipset Voltages, Memory
FAN
  • Fans with tachometer monitoring
  • Status monitor for speed control
  • Pulse Width Modulated (PWM) fan connectors
Temperature
  • Monitoring for CPU and chassis environment
  • Thermal Control for fan connectors
Chassis
Form Factor 2U Rackmount
Model CSE-MG202TS-R000NDFP
Dimensions and Weight
Height 3.43″ (87 mm)
Width 17.3″ (438.4 mm)
Depth 35.43″ (900 mm)
Package 11.02″ (H) x 27.56″ (W) x 47.24″ (D)
Weight
  • Gross Weight: 103 lbs (46.8 kg)
  • Net Weight: 88 lbs (40 kg)
Available Color Silver
Front Panel
Buttons Power On/Off
LED HDD activity
Expansion Slots
PCI-Express (PCIe) Configuration
Drive Bays / Storage
Drive Bays Configuration
  • Default: Total 3 bays
  • 3 front fixed E1.S NVMe drive bays
M.2
System Cooling
Fans 6 Removable heavy-duty 6cm Fan(s)
Power Supply
4x 2000W Redundant (2 + 2) Titanium Level (96%) power supplies
Dimension (WxHxL) 73.5 x 40 x 185 mm
Input
  • 1000W: 100-127Vac / 50-60Hz
  • 1800W: 200-220Vac / 50-60Hz
  • 1980W: 220-230Vac / 50-60Hz
  • 2000W: 220-240Vac / 50-60Hz (for UL only)
  • 2000W: 230-240Vac / 50-60Hz
  • 2000W: 230-240Vdc / 50-60Hz (for CQC only)
+12V
  • Max: 83A / Min: 0A (100Vac-127Vac)
  • Max: 150A / Min: 0A (200Vac-220Vac)
  • Max: 165A / Min: 0A (220Vac-230Vac)
  • Max: 166A / Min: 0A (230Vac-240Vac)
12V SB Max: 3.5A / Min: 0A
Output Type Backplanes (gold finger)
Operating Environment
Environmental Spec.
  • Operating Temperature: 10°C to 30°C (50°F to 86°F)
  • Non-operating Temperature: -40°C to 60°C (-40°F to 140°F)
  • Operating Relative Humidity: 8% to 90% (non-condensing)
  • Non-operating Relative Humidity: 5% to 95% (non-condensing)
