GPU ARS-111GL-SHR / 1U | Taknet
  • Supermicro

GPU ARS-111GL-SHR / 1U

Key Applications

  • High Performance Computing
  • AI/Deep Learning Training and Inference
  • Large Language Model (LLM) and Generative AI

Key Features

  1. NVIDIA GH200 Grace Hopper™ Superchip, up to 72 cores
  2. Up to 480GB ECC LPDDR5X embedded on the NVIDIA Superchip
  3. Up to 3 PCIe 5.0 x16 FHFL slots
  4. Up to 8 front hot-swap E1.S NVMe drive bays Supports 8 E1.S Drives as opposed to NHR version which supports 2.
  5. 2 Redundant 2000W Titanium Level power supplies
  6. Support for up to 1 embedded on the NVIDIA Grace Hopper Superchip:qty string GPU accelerator cards Supports 8 E1.S Drives DC-SCM Support
  7. 1U Rackmount chassis with 37″ (940mm) depth

Categories

Download datasheet

Product Specifications

Product SKUs
SuperServer ARS-111GL-SHR
Motherboard
Super G1SMH-G
Processor
CPU NVIDIA 72-core NVIDIA Grace CPU on GH200 Grace Hopper™ Superchip
Note Supports up to 1000W TDP CPUs (Air Cooled)
GPU
Max GPU Count 1 onboard GPU
Supported GPU
  • NVIDIA: H100 Tensor Core GPU on GH200 Grace Hopper™ Superchip (Air-cooled)
CPU-GPU Interconnect NVLink®-C2C
System Memory
Memory
  • Slot Count: Onboard Memory
  • Max Memory: Up to 480GB ECC LPDDR5X
  • Additional GPU Memory: Up to 96GB ECC HBM3
On-Board Devices
Chipset System on Chip
Network Connectivity View AOC Options
Input / Output
LAN 1 RJ45 1 GbE Dedicated BMC LAN port
USB 1 USB 3.0 port(Rear)
Video 1 mini-DP port
TPM 1 TPM Onboard/port 80
System BIOS
BIOS Type AMI 64MB SPI Flash EEPROM
Management
Power Configurations
  • Power-on mode for AC power recovery
  • ACPI Power Management
PC Health Monitoring
CPU Monitors for CPU Cores, Chipset Voltages, Memory
FAN
  • Fans with tachometer monitoring
  • Status monitor for speed control
  • Pulse Width Modulated (PWM) fan connectors
Temperature
  • Monitoring for CPU and chassis environment
  • Thermal Control for fan connectors

Chassis
Form Factor 1U Rackmount
Model CSE-MG102TS-R000NDFP
Dimensions and Weight
Height 1.7″ (43.6 mm)
Width 17.26″ (438.4 mm)
Depth 35.4″ (900 mm)
Package 9.05″ (H) x 27.36″ (W) x 46.06″ (D)
Weight
  • Gross Weight: 49.49 lbs (22.45 kg)
  • Net Weight: 33.84 lbs (15.35 kg)
Available Color Silver
Front Panel
Buttons Power On/Off button
Expansion Slots
PCI-Express (PCIe) Configuration
Drive Bays / Storage
Drive Bays Configuration
  • Default: Total 8 bays
  • 8 front hot-swap E1.S NVMe drive bays
M.2
System Cooling
Fans 9 Removable heavy-duty 4cm Fan(s)
Power Supply
2x 2000W Redundant Titanium Level (96%) power supplies
Dimension (WxHxL) 73.5 x 40 x 185 mm
Input
  • 1000W: 100-127Vac / 50-60Hz
  • 1800W: 200-220Vac / 50-60Hz
  • 1980W: 220-230Vac / 50-60Hz
  • 2000W: 220-240Vac / 50-60Hz (for UL only)
  • 2000W: 230-240Vac / 50-60Hz
  • 2000W: 230-240Vdc / 50-60Hz (for CQC only)
+12V
  • Max: 83A / Min: 0A (100Vac-127Vac)
  • Max: 150A / Min: 0A (200Vac-220Vac)
  • Max: 165A / Min: 0A (220Vac-230Vac)
  • Max: 166A / Min: 0A (230Vac-240Vac)
12V SB Max: 3.5A / Min: 0A
Output Type Backplanes (gold finger)
Operating Environment
Environmental Spec.
  • Operating Temperature: 10°C to 35°C (50°F to 95°F)
  • Non-operating Temperature: -40°C to 60°C (-40°F to 140°F)
  • Operating Relative Humidity: 8% to 90% (non-condensing)
  • Non-operating Relative Humidity: 5% to 95% (non-condensing)
